den-kimi zei:

http://www.groupbrally.com/images/audi/rs002/0.jpg

Audi Sport Quattro RS 002

de wagen die de quattro s1 had moeten opvolgen.

Klik om te vergroten...

den-kimi zei:

Audi Sport Quattro RS 002

de wagen die de quattro s1 had moeten opvolgen.

Klik om te vergroten...

Lancia ECV1 (Group S Prototype)
First displayed at the Bologna Motorshow in 1986, the ECV1 (Experimental Composite Vehicle) was a composite technology concept car testing the use of carbon, kevlar, thermosetting and thermoplastic resins, glassfibre and honeycomb in car production. It was also considered Lancia's prototype Group S car (a formula which never came to fruit). It was a further development of the S4, featuring the same basic design, with many of the components now made from composites, including the main, load bearing part of the body. Other composite parts included the wheels (8x16" wheels weighing only 6kg !) and the propshaft. It was powered by a 1759cc twin turbo (two KKK units) engine producing 600bhp @ 8,000rpm using a new design known as "triflux" where the two turbochargers were used sequentially depending on the engine speed. An overall weight of 930kg was achieved.

The 1800cc power unit of the ECV1 & 2 was known as the triflux. This was due to the design which had one exhaust and one inlet valve on each side of the cylinder head, with the resulting twin exhaust manifolds each feeding one turbocharger. At low engine speeds one turbocharger exhaust was shut-off, forcing all the exhaust gases through one unit and thus providing good low speed performance. As the engine speed rose, the second turbocharger was gradually introduced, until at high engine speeds both turbochargers ran in parallel.

Klik om te vergroten...

Lancia EVC2
The ECV2 was a further development of the theme, with an all new bodywork which was aerodynamically optimised, the major change being the relocation of the engine coolant and lubricant radiators to the front of the car. The body construction continued the theme of the ECV1, using aluminium honeycomb, carbon fibre, glass fibre and kevlar in various positions. The weight distribution was also improved with respect to the previous model. The engine remained 1759cc with two turbochargers using the triflux system. The intercoolers also adopted water cooling. The drive system remained essentially as in the S4, with some improvements, a three-differential design with 30% of the torque at the front and the remaining 70% at the rear. Ventilated disc brakes, power assisted steering and double wishbone suspension all round were also used. The wheelbase was 2440mm, the tracks (front/rear) 1500mm/1520mm and kerb weight 910kg.

Klik om te vergroten...

den-kimi zei:

dezelfde maar dan dichter. alle rommel die ge ziet is vastgelijmd

Klik om te vergroten...

128MB zei:

kzit hier in de camionette langs de baan strijk te gaan
